Code name:

YJ: XLPE insulation
V: PVC sheath
32:Steel wire armoring
22:Steel tape armoring
72: Aluminum wire armoring—1 core
62: Stainless steel tape armoring—1 core
ZR: Flame resistant

Application

For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.

Standard

International: IEC 60502, IEC 60228
China: GB/T 12706
Other standards such as BS, DIN and ICEA upon request

Technical data:

Rated voltage:6/10kV

Maximum Conductor Temperature: under normal (90^OC), emergency (130^OC) or short circuit no more than 5 s (250℃) conditions.

Min. Ambient Temp. 0^OC, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D for single core

15 x cable O.D for multi core

Nom. Cross-section of conductor	Strands No./Dia. Of Conductor	Insulation Thickness	Inner Sheath Thickness	Dia. Of Armor Wire	Sheath Thickness	Approx. O.D.	Approx. Weight	Max. D.C Resistance of Conductor (20 ℃)	Testing Voltage A.C	Current Rating
mm2	pc/mm	mm	mm	mm	mm	(mm)	kg/km	Ω /km	kV/5min	In air (A)	In soil(A)
3 × 50	10/2.52	8	1.8	3.15	3.5	80.0	9376	0.387	63	175	180
3 × 70	14/2.52	8	1.8	3.15	3.6	84.0	10426	0.268	63	220	220
3 × 95	19/2.52	8	1.8	3.15	3.7	87.0	11475	0.193	63	255	265
3 × 120	24/2.52	8	1.8	3.15	3.8	90.0	12598	0.153	63	290	300
3 × 150	30/2.52	8	1.8	3.15	3.9	93.0	13855	0.124	63	330	340
3 × 185	37/2.52	8	1.8	3.15	4.0	96.0	15233	0.0991	63	435	380
3 × 240	48/2.52	8	2.0	3.15	4.2	102.0	17481	0.0754	63	495	435
3 × 300	61/2.52	8	2.0	3.15	4.4	107.0	19731	0.0601	63	565	485
3 × 400	61/2.97	8	2.0	3.15	4.6	114.0	23422	0.0470	63	640	520

Tags:

Kreuz verbundenes Polyäthylenkabel,

EINZELHEITEN ZU DEN PRODUKTEN

Produits

XLPE-isolierte Kabel

PVC-Kabel

Mineralisolierte Kabel

gepanzertes elektrisches Kabel

Mehradriger Seilzug

einkerniger Draht

Abgeschirmtes Instrument-Kabel

niedriger Rauch null Halogenkabel

Feuerbeständige Kabel

Flammhemmendes Kabel

Gummiflachkabel

Antenne zusammengerolltes Kabel

Bloßer Leiter

flexibles elektrisches Kabel

Solarpv-Kabel

Vorfabriziertes Niederlassungs-Kabel

Hohe Temperatur-Kabel

Kupfer verkleidet Aluminium Draht

Flexibles Schweißkabel

Brennschneiderkabel

Compact XLPE Insulated PVC Sheathed Cable Outer Semi - Conductive Layer

MOQ:	800Meter
Preis:	USD 6.25-29.99/M
Standardverpackung:	Hölzerne Trommel
Lieferfrist:	10 TAGE
Zahlungsmethode:	L/C, T/T,
Lieferkapazität:	100KM/week

Einzelheiten

Produktbeschreibung

Einzelheiten

Herkunftsort

China

Markenname

QINGDAO YICABLE CABLE

Zertifizierung

KEMA/CE/ISO/TUV/RoSH

Leiter:

Kupfer

Isolierung:

XLPE

Biegen:

15XO.D

Hörbeispiel:

frei

Isolierungsfarbe:

ROT, GELB, BLAU

Funktionierender Temp:

90 Grad

Hülle:

ZR-PVC Art ST2 zu Iec 60502

Min Bestellmenge:

800Meter

Preis:

USD 6.25-29.99/M

Verpackung Informationen:

Hölzerne Trommel

Lieferzeit:

10 TAGE

Zahlungsbedingungen:

L/C, T/T,

Versorgungsmaterial-Fähigkeit:

100KM/week

Hervorheben

xlpe electrical cable

xlpe power cable

Produktbeschreibung

Three Core Copper Conductor XLPE Insulated Medium Voltage 11kV Power Cable

Construction

Conductor : Compact stranded copper conductor, Cl.2 as per IEC 60228

Conductor Screen: Semi-conductor

Insulation : XLPE(cross-linked polyethylene) rated at 90 OC

Insulation Screen: Semi-conductor

Screen : Copper tape

Sheath : PVC or FR-PVC type ST2 to IEC 60502, black
