3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring
  • Name
  • Name
  • Name
  • Name

3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring

MOQ: 500
Preis: USD 1-100 Per Meter
Standardverpackung: Eisen-hölzerne Trommel oder hölzerne Trommel
Lieferfrist: 15 Tage
Zahlungsmethode: L/C, T/T, Western Union, MoneyGram
Lieferkapazität: 1000KM PRO MONAT
Einzelheiten Informationen
Produktbeschreibung
Einzelheiten
Herkunftsort
China
Markenname
QINGDAO YICABLE CABLE
Zertifizierung
IEC/CE/KEMA
Nennspannung:
0.6/1kV
Dirigent Typ:
Angeschwemmter Leiter (Klasse 2)
Kern-Kennzeichen:
Zahl oder Farbstreifen
Biegungsradius:
Leiter des Rundschreibens 6D
Trommel-Länge:
500m oder gemäß des Antrags
Max. Betriebstemperatur:
90℃
Hervorheben:

xlpe electrical cable

,

cross linked polyethylene cable

Produktbeschreibung

3 Core Copper Low Voltage Power Cables For Industrial Wiring and Mains Distribution

Applications: Industrial wiring and mains distribution. Can be laid direct in the ground, or in ducts, clipped to surface, on trays or in free air.



CONSTRUCTION



Conductor : Single, Two, Three, Four and Five core cables. Stranded plain copper conductors Insulation : XLPE insulated, cores laid up, extruded PVC bedding, galvanised steel wire armoured (Aluminium wires for single cores) and PVC sheathed.



STANDARD COLOURS



Cores : Single-core- Red or Black 2-core- Red and Black 3-core- Red, Yellow and Blue 4-core- Red, Yellow, Blue and Black 5-core- Red, Yellow, Blue, Black and Green/Yellow As per New Harmonised Code Single-core- Brown or Blue 2-core- Brown and Blue 3-core- Brown, Black and Grey 4-core- Brown, Black Grey and Blue 5-core- Brown, Black, Grey, Green/Yellow and Blue



PROPERTY:



1.The highest allowed operating temperature of conductor for long-term working is 90 degrees. 2.In short circuit (Max long term is no more than 5 seconds),the highest temperature for conductor is no more than 250 degrees. 3.The cable is laid without horizontal drop limit. The environment temperature should be no lower than 0 when lay. Otherwise it should be preheated. 4.Excellent electrical performance, resistance to chemical corrosion. 5.They can stand advisable traction when laid. They can stand traction from Outside. Left low smoke halogen-free after burned. Retard the burning of the cabl




Ordering Advice

Rated Voltage
Application Standard: IEC/BS/UL/GB
Number of Cores
Conductor Size & Construction
Type of Insulation
Armored or unarmored. If armor, the armor type & material
The Requirement of Sheath
Length of Cable & Packing Requirement
Other Requirement


3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring 0




Tags:

Kreuz verbundenes Polyäthylenkabel,

VPE Stromkabel,

xlpe elektrisches Kabel
