XLPE isolierte obenliegendes Aluminium-Kabel der Energie-11kv
Spezifikation und Parameter von Kabel Millivolts ABC
6.35-/11kV u. 12.7-/22kVabc Cable-AS/NZS 3599,1 Standard |
Zahl des Nennquerschnitts der Kerne x |
Nominaler Leiterdurchmesser |
Nominale Isolierungsstärke |
Nominale Isolierungsschirmstärke |
Nominale Hüllenstärke |
Leitergröße der Unterstützungs AAAC/1120 |
Nominaler Gesamtdurchmesser |
Gewicht |
Bewertung des stationären Gleichstroms, A |
Noch Luft |
Wind 1m/s |
Wind 2m/s |
mm^2 |
Millimeter |
Millimeter |
Millimeter |
Millimeter |
No/mm |
Millimeter |
kg/km |
|
|
|
6.35/11kV |
3x35 |
6,9 |
3,4 |
0,8 |
1,2 |
7/4.75 |
52,4 |
1370 |
110 |
155 |
185 |
3x50 |
8,1 |
3,4 |
0,8 |
1,2 |
7/4.75 |
54,6 |
1530 |
130 |
185 |
225 |
3x70 |
9,7 |
3,4 |
0,8 |
1,2 |
7/4.75 |
57,8 |
1790 |
160 |
235 |
280 |
3x95 |
11,4 |
3,4 |
0,8 |
1,2 |
7/4.75 |
61,3 |
2100 |
195 |
285 |
345 |
3x120 |
12,8 |
3,4 |
0,8 |
1,2 |
19/3.50 |
67,3 |
2540 |
230 |
335 |
405 |
3x150 |
14,2 |
3,4 |
0,8 |
1,2 |
19/3.50 |
70,1 |
2840 |
255 |
380 |
460 |
3x185 |
15,7 |
3,4 |
0,8 |
1,2 |
19/3.50 |
73,1 |
3190 |
295 |
440 |
530 |
12.7/22kV |
3x35 |
6,9 |
5,5 |
0,8 |
1,2 |
7/4.75 |
61 |
1780 |
110 |
155 |
180 |
3x50 |
8,1 |
5,5 |
0,8 |
1,2 |
7/4.75 |
63,3 |
1970 |
130 |
185 |
220 |
3x70 |
9,7 |
5,5 |
0,8 |
1,2 |
7/4.75 |
66,5 |
2260 |
160 |
230 |
275 |
3x95 |
11,4 |
5,5 |
0,8 |
1,2 |
7/4.75 |
69,9 |
2600 |
195 |
285 |
335 |
3x120 |
12,8 |
5,5 |
0,8 |
1,2 |
19/3.50 |
75,9 |
3070 |
225 |
330 |
395 |
3x150 |
14,2 |
5,5 |
0,8 |
1,2 |
19/3.50 |
78,7 |
3390 |
255 |
375 |
450 |
3x185 |
15,7 |
5,5 |
0,8 |
1,2 |
19/3.50 |
81,7 |
3760 |
290 |
435 |
520 |
